SPECIFICATION
| Diameter Speaker (inch/mm) Impedansi (Ω) Nominal power handling (Watt) ¹ Program power (Watt)² Lebar daerah frekuensi (Hz) SPL (2.83 V / 1 m) (dB) Diameter cone efektif (mm) Medan magnet (T) Berat magnet (Kg/Oz) Voice coil diameter (mm) Voice coil material |
6 inch / 152.4 mm 8 Ω 180 Watt 360 Watt 235 Hz – 7800 Hz 99 dB 132 mm 1.78 T 0.4 kg /14.1 Oz 49.5 mm TILL |
Parameter “Thiele-Small”
| Frekuensi Resonansi / Fs (Hz) DCR (Ω) Qts Qes Qms Mms (g) Cms (mm/N) BL Product (Tm) Vas (liters) No (%) Sd (cm2) Xmax (mm) |
235 Hz 5.6 Ω 0.50 0.60 2.97 12.1 g 0.04 mm/N 13.1 Tm 1.0 liters 1.82 % 136.8 cm2 3.42 mm |
– (¹) AES standard, test mode with continuous pink noise signal (6 dB crest factor; 2 hours) within the Fo to 10Fo power calculated on rated nominal impedance. Loudspeaker in free air
– (²) Power on continous program is defined as 3dB greater than nominal power handling.
