- Description
Description
datasheet
SPECIFICATION (PRELIMINARY DATA)
| Diameter Speaker (inch/mm) Impedansi (Ω) Max Power (Watt) Lebar daerah frekuensi (Hz) SPL (2.83 V / 1 m) (dB) Diameter cone efektif (mm) Medan magnet (T) Berat magnet (Kg/Oz) Voice coil diameter (mm) Voice coil material |
12 inch / 304.8 mm 8 Ω 300 Watt 55 Hz – 14900 Hz 96 dB 259 mm 1.03T 1.00 kg /35.1 Oz 38.5 mm / 1.5 inch Kapton |
THIELE SMALL PARAMETER
| Frekuensi Resonansi / Fs (Hz) DCR (Ω) Qts Qes Qms Mms (g) Cms (mm/N) BL Product (Tm) Vas (liters) No (%) Sd (cm²) Xmax (mm) |
55 Hz 6.2 Ω 0.94 1.00 14.02 42.9 g 0.20 mm/N 9.6 Tm 76.3 liters 1.21 % 526.9 cm² 5.71 mm |
