1. Weatherproof Cone Paper
The cone paper is made using special materials, resulting in a strong cone paper that delivers excellent sound. The cone paper is also coated with a weatherproof layer, making it suitable for both indoor and outdoor applications.
2. Optimal Magnetic Power
The motor design, which has undergone FEA (Finite Element Analysis) measurements, provides optimal magnetic power, coupled with thicker magnet dimensions, resulting in better bass sound.
3. Wide Bandwidth
The special speaker design produces a wide operating frequency range from 50 Hz to 6500 Hz.
4. Good Air Compression
The cone paper is equipped with ventilation on the inner diameter of the cone for good air circulation and reduced air compression during operation. 5. Maximum Power Handling The voice coil is coated with a cemedine coating, allowing the speaker to withstand even high temperatures and power handling.
| Specifications | |
| Speaker Diameter | 6 inch |
| Impedance | 8 Ω |
| Nominal Power Handling | 50 W |
| Program Power | 100 W |
| Frequency Response | 50 - 6000 Hz |
| Sensitivity | 89 dB |
| Effective Cone Diameter | 130 mm |
| Magnetic flux density | 0.87 T |
| Magnet Weight | 0.36 kg |
| Speaker Weight | 0.87 kg |
| Voice Coil Diameter | 25.4 mm |
| Voice Coil Material | Kapton |
| Magnet Material | Ferrite |
| Thiele-Small Parameters | |
| Frequency Response | 50 Hz |
| DCR | 5.2 Ω |
| Qts | 0.42 |
| Qes | 0.46 |
| Qms | 4.86 |
| Mms | 15.2 g |
| Cms | 0.68 mm/N |
| BL Product | 7.3 Tm |
| Vas | 16.8 litres |
| No | 0.43 % |
| Sd | 132.7 cm² |
| Xmax | 5.38 mm |
