Optimized Driver Motor Structure Design
The motor structure is designed using ferrite magnets that have been optimally simulated with FEMM and is equipped with a specially designed motor structure to deliver excellent response quality at high frequencies.
Wider Frequency Range with Low-Distortion Motor System
A specially designed dome made from composite titanium allows the compression driver to produce a wider frequency range (1000 Hz – 20,000 Hz), supported by a specially designed motor system to reduce distortion in the compression driver.
Ideal for Compact 2-Way Systems & Multi-Driver Line Array Systems
The 2.55-inch (75 mm) voice coil design using pure aluminum wire with a 1.4-inch (35.6 mm) exit throat on the compression driver is highly suitable and ideal for compact 2-way systems and multi-driver line array systems, delivering improved sound quality.
| Specifications | |
| Impedance | 8 Ω |
| Nominal Power Handling(1) | 100 W |
| Program Power(2) | 200 W |
| Frequency Response | 1000 – 20000 Hz |
| Sensitivity | 99 dB |
| Magnetic flux density | 1.65 T |
| Magnet Weight | 1.6 kg |
| Speaker Weight | 4.42 kg |
| Voice Coil Diameter | 74.5 mm |
