Optimal Driver Motor System
The driver motor design uses a ferrite magnet with Ferrofluid, providing better heat resistance and more stability at high frequencies.
Smoother and Flatter Frequency Response Ripple at High Frequencies
A specially designed phase plug and horn adapter, optimized through FEA simulation, result in a smooth and flat frequency response ripple at high frequencies.
Exceptional Sound Output
A specially designed dome made from titanium and using an aluminum SV former delivers excellent high-frequency response with a distinctive sound character.
| Specifications | |
| Impedance | 8 Ω |
| Nominal Power Handling(1) | 20 W |
| Program Power(2) | 40 W |
| Frequency Response | 2500 – 20000 Hz |
| Sensitivity | 99 dB |
| Magnetic flux density | 1.6 T |
| Magnet Weight | 0.28 kg |
| Speaker Weight | 0.8 kg |
| Voice Coil Diameter | 25.4 mm |
