Weatherproof Conepaper
Made from 100% UKP material, the conepaper is strong and capable of producing excellent sound quality. It is also coated with a weatherproof layer, making it suitable for both indoor and outdoor use.
Optimized Magnet Power
The motor is designed using Finite Element Analysis (FEA), resulting in optimized magnetic performance for improved speaker efficiency.
Wide Bandwidth Frequency Response
A specially engineered speaker design delivers a wide operating frequency range from 60 Hz to 11,700 Hz, ensuring clear and detailed audio across the spectrum.
Efficient Airflow and Compression Control
The conepaper includes ventilation around the inner diameter area, providing effective airflow to reduce air compression during operation and maintain performance stability.
| Specifications | |
| Speaker Diameter | 6 inch |
| Impedance | 6 Ω |
| Nominal Power Handling | 20 W |
| Program Power | 40 W |
| Frequency Response | 60 – 11700 Hz |
| Sensitivity | 88 dB |
| Magnetic flux density | 1.12 T |
| Magnet Weight | 0.27 kg |
| Voice Coil Diameter | 25.4 mm |
| Voice Coil Material | ASV |
| Thiele-Small Parameters | |
| Fs | 60 Hz |
| DCR | 5 Ω |
| Qts | 0.8 |
| Qes | 1.1 |
| Qms | 3.02 |
| Mms | 11.3 g |
| Cms | 0.57 mm/N |
| BL Product | 4.5 Tm |
| Vas | 13.3 litres |
| No | 0.25 % |
| Sd | 128.7 cm² |
| Xmax | 4.8 mm |
