Optimal Magnetic Power
The motor is designed using FEA (Finite Element Analysis), resulting in optimal magnetic performance.
Weather-Resistant Conepaper
The conepaper is made from special paper processed using the “rigid non-press” method and coated with a weather-resistant layer, making the speaker suitable for both indoor and outdoor applications.
Low Compression
The motor and chassis are designed with additional ventilation to eliminate air compression and provide airflow that functions as a cooling system.
Smooth Frequency Response
The conepaper features a triple-roll cloth surround with damping glue, delivering a smooth and refined frequency response.
Maximum Power Handling
The voice coil winding is coated with a special layer, allowing it to endure high temperatures so the speaker can reliably handle high power levels.
| Specifications | |
| Speaker Diameter | 15 inch |
| Impedance | 8 Ω |
| Frequency Response | 40 - 3600 Hz |
| Sensitivity | 96 dB |
| Magnetic flux density | 1.06 T |
| Magnet Weight | 1.76 kg |
| Voice Coil Diameter | 75.6 mm |
| Voice Coil Material | Till |
| Maximum Power | 1000 W |
| Thiele-Small Parameters | |
| Fs | 40 Hz |
| DCR | 5.2 Ω |
| Qts | 0.43 |
| Qes | 0.46 |
| Qms | 6.61 |
| Mms | 99.8 g |
| Cms | 0.16 mm/N |
| BL Product | 16.9 Tm |
| Vas | 165 litres |
| No | 2.26 % |
| Sd | 865.7 cm² |
| Xmax | 7.94 mm |
